MicroStation Tools

Generic State Machine

DgnElementSetTool class implements a state machine. Here's an example of a simple state diagram  …

As the machine received events and actions, it moves from one state to another. In the above diagram, Event0/Action1 causes nothing to happen and the machine remains in State0. Event1/Action2 causes the machine to change from State0 to State1. Event1/Action4 causes the machine to change from State1 to State0.

MicroStation State Machine

Suppose you start a MicroStation Place Line tool …

1. Initial state: When you start the tool, you see a prompt (e.g. Place Line)
2. Datapoint state: Once you've placed the first point, the tool changes state: it prompts for another point (e.g. Place Next Point)
3. Create state: After placing the required number of points, the tool changes state again: it's able to complete its task (e.g. Creates a DGN line element)
4. Reset state: If the tool is finished, or perhaps you press Reset, the tool reverts to state 1

That's an example of a simple three-state machine. It's implemented using the DgnElementSetTool class.

Other State Machines

MicroStation Python offers more specialised state machines that inherit from DgnElementSetTool. Read about them here.

Inherit from DgnElementSetTool class

Write your own tool for MicroStation that emulates the idioms of the built-in tools. Start by inheriting from DgnElementSetTool …

class ElementPicker(DgnElementSetTool):

You're creating a Python class, so initialise your tool with the __init__ method …

    def __init__(self, toolId: int):
        """
        Initialize the ElementPicker.

        param toolId: The ID of the tool.
        """
        DgnElementSetTool.__init__(self, toolId) # C++ base's __init__ must be called.
        self.m_isDynamics = False
        self.m_ev = None
        self.m_self = self # Keep self-referenced. This variable is used by the base class DgnElementSetTool.

DgnElementSetTool Notes

• self.m_self is assigned, but you won't see it used. I assume that DgnElementSetTool uses it internally
• Super-class __init__ is called explicitly: DgnElementSetTool.__init__(self, toolId)
• m_isDynamics is a flag that indicates when you need to draw graphics in dynamics. For example, when you place a line-string or shape and want to 'rubber-band' a preview of the object
• m_ev is a DgnButtonEvent that your code may receive at certain stages (e.g. user placed a datapoint)

Message Lists

"What is toolId?" I hear you ask. In Python it's an enigma. Most of MicroStation Python is derived from the C++ MicroStationAPI. That API and its predecessor MDL use message lists to store translatable message resources. A message list is identified by an integer ID, and each message in that list also has an integer ID. Using C++, there are functions that provide access to messages using those IDs.

Unfortunately, Python has no way of building a message list, nor does it have access to existing message resources. toolId is an unused and unusable relic of MicroStation Python's journey from the MicroStationAPI. toolId does nothing: you can't use it.

DgnElementSetTool Summary

I've extracted a summary of DgnElementSetTool event handlers. Look at the Python examples to see how those handlers are used.

Python Examples

MicroStation Python Examples

There are Python examples that use DgnElementSetTool delivered with your MicroStation installation. You'll find those examples in your computer's local drive. They are likely to be found in this folder …

C:\ProgramData\Bentley\PowerPlatformPython\Examples\Microstation\DgnElements\

LA Solutions Examples

You'll find Python examples written by LA Solutions on these pages, starting here.

---

Visit the LA Solutions' State Machine examples Download page.
